680K Ohm 1/2W 5% Carbon Film Axial Resistor | PTH Resistor for Electronics

680 K ohm 1/2W 5% Carbon Film Resistors

680K Ohm (680,000 Ohm) carbon film resistor with a nominal power of 0.5 Watt and ±5% tolerance. Designed for low-power electronic circuits, it offers high stability in general-purpose applications thanks to carbon film technology.

The axial lead construction allows for easy insertion into PTH (Pin Through Hole) printed circuit boards. The body is covered with epoxy resin for effective protection against mechanical stress and environmental conditions.

Technical specifications:

• Resistance value: 680 KOhm (680,000 Ohm)
• Rated power: 0.5W (1/2 Watt)
• Tolerance: ±5%
• Technology: Carbon Film
• Rated voltage: 350V
• Overload voltage: 700V
• Terminals: Axial
• Mounting: PTH (Pin Through Hole)
